Bowl Filter Rac500Ma30 - Compact Filtration Solution For Various Applications

Racor Water seperator Diesel Engines: Impeller type: When an engine requires a large capacity of water separation and filtration fuel, an impeller type is the most efficient and reliable way of protection. How it works (Figure 2): 1.-As the fuel enters, it circulates around and through the turbine centrifuge, impurities and drops of water dripping and droplets heavier than fuel, on the bottom of the drip tray. 2 - Smaller water droplets spread over the sides of the filter and the element. When this is sufficient heavy are stray / fall also to the bottom of the collection bin. 3 - In addition to shedding water and small solids, it filters: algae, oxide, rust from the fuel by Aquabloc elements, these are waterproof and long-lasting. The Racor 500MA Series Fuel Filter/Water Separator protects the precision components of your engine from dirt, rust, algae, asphaltines, varnishes and especially water which is prevalent in engine fuels. Features: Removes 99 percent of free water and sediment Includes 30 micron element - 2010PM-OR 2-port, with 3/4-16 UNF (SAE J1926 female threads) Filters diesel fuel The lower the micron rating, the finer the filtration. Follow your engine manufacturer's recommendation for fuel filter micron rating. S = Secondary/Final 2 micron (Brown) T = Primary or Secondary/Final 10 micron (Blue) P = Primary 30 micron (Red) Spare filter elements: Ref 500 Ref 900 Ref 1000 Micrometer RAC2010SM-OR RAC2040SM-OR RAC2020SM-OR 2 RAC2010TM-OR RAC2040TM-OR RAC2020TM-OR 10 RAC2010PM-OR RAC2040PM-OR RAC2020PM-OR 30 Adaptor RAC3/8F-3/8M is needed for hose fitting
